Bowler 200-4R Lock-Up Control Module

Complete 200-4R lock-up control kit with automatic 4th-gear activation, internal harness with solenoid and pass-through connector, gasket, filter, and optional brake switch

SKU: 5102000

The Bowler Performance 200-4R Lock-Up Control Module provides smooth, predictable, automatic torque converter lock-up without vacuum switches, extra boxes, or complicated wiring. Designed specifically for the 200-4R, this module engages lock-up 8–10 seconds after 4th gear, allowing the engine to gain RPM before locking in. This eliminates early bogging, chugging at cruise, and drivability issues common with stock-style lock-up setups.

The module features an integrated GM 4-pin connector and epoxy-coated electronics for long-term heat and vibration protection. Installation is simple, clean, and requires only a fused 12V ignition feed.

Perfect for hot rods, restomods, cruisers, and performance builds running a 200-4R transmission.

Key Features

• Automatic converter lock-up 8–10 seconds after 4th gear
• No vacuum switch required — works with carb, EFI, or boosted engines
• No bulky external box — GM 4-prong connector integrated into the board
• Epoxy-coated for weather resistance and durability
• Simple one-wire hookup (2-amp fused 12V ignition)
• Reduces chugging, surging, and premature lock-up bog
• Improves throttle response and highway drivability
• Full kit—no extra parts needed

What’s Included

• Lock-Up Control Module
• New Internal Wiring Harness with Lock-Up Solenoid
• Solenoid mounting studs
• Case pass-through connector
• Pressure Switch
• Pan Gasket
• New Transmission Filter
• Brake Switch Function

The included brake switch improves lock-up control by allowing the driver to tap the brake and instantly unlock the converter. Ideal for:

• Climbing inclines
• Tall gear ratios
• Late downshift situations
• Eliminating lock-up “chugging”

The switch is optional, but highly recommended for best drivability.

Why Choose Bowler

• Designed specifically for 200-4R applications
• Cleaner installation than toggle switches or universal lock-up kits
• No tuning, no vacuum setup, no wiring guesswork
• Complete internal harness and case connector included
• Engineered for long-term durability and consistent lock-up behavior
• Trusted by top builders and shops nationwide

Instructions

200-4R Lock-Up Installation Instructions
